Powerful, reliable and compact
• designed and manufactured based on DIN 14963
• Smallest dimenssions
• Little weight
• Rapid deployment with one easy movement
• Thanks to targeted and powerful airflow, smoke is quickly removed from the scene.
• Its unique function ensures optimum performance.
• Extremely compact design, minimal footprint in vehicle, ideally suited for aerial ladder, staper and rescue stairs.
• Maximum inclination adjustment (-6° up to +20°)
• Large, smooth-operating wheels
• Robust adjustment mechanism
• Stable vibration dampers
• Integrated water spray device
Safe ventilation in the most difficult conditions:
Thanks to the high performance airflow and the large adjustment range, from -6° to +20°, better ventilation is possible even with higher level doors, external entrance steps, basement stairs etc.
The direct drive supplies an extremely powerful airflow: less noise, less wear parts.
Integrated water spray device:
Can be used for generating a water spray (200l at 5 bar).
Space saving and rapid deployment for lightfoam production. Can be used as a lightfoam generator when fitted with foam net and foam proportioner.
Technical data:
S: 3,45 kVA
U: 230 V/ 1~
I: 15 A
f: 50 Hz
Connecting cable: 2 m with Schuko plug IP68
Protection class: IP 54
Air outlet diameter: approx. 16″ / 410 mm
Airflow according to ISO 5801: 5606 m³/h
Thrust according to ISO 13350: 25,8 N
noise emission [dB(A)]: 89 dB(A) at 100 % rotational frequency
Dimensions (W x H x D): 490 x 615 x 450 mm
Weight (ready for use): approx. 41 kg
